Bose AV28 User Manual

54
Main PCB 260318-0
Electrical Part List
(Transistors continued)
Reference
Designator
Description Part Number Note
Q303 NPN, SOT, 2SC4695 148770
Q304 NPN, SOT, 2SC4695 148770
Q601 NPN, SOT, 47K 146817
Q602 NPN, SOT, MMBT3904 146819
Q603 NPN, SOT, MMBT3904 146819
Q703 NPN, SOT, 47K 146817
Q705 SOT-23 260354-001
Q706 SOT-23 260354-001
Q801 NPN, 15V, 200MA, SOT-23 254111-001
Q802 PNP, SOT, MMBT3906 148596
Q803 NPN, SOT, 47K 146817
Q804 NPN, 15V, 200MA, SOT-23 254111-001
Q805 NPN, SOT, 47K 146817
Q1000 IR RECEIVER MODULE 256780-001
(Integrated Circuits continued)
Reference
Designator
Description Part Number Note
U1 DVD DECODER, CS98000 254107-001
U2 FLASH, 16M, 3.3V, TSSOP, 90NS
(01.03.06
)
307513
U3 SDRAM, 64MBIT, 2MX32, 3.3V 254182-080
U201 AUDIO MATRIX, SO28 177984-2
U202 DAC, 96KHZ, 3-5V, CS4340-KS 256087-001
U204 OPAMP, DUAL, SINGLE SUPPLY 256740-001
U205 OPAMP, DUAL, HI CURRENT 256741-001
U302 QUAD 2 CHANNEL MUX, 74LCX157 260377-001
U303 CODEC AUDIO, CS4224, SSOP28 254153-001
U304 QUAD 2 CHANNEL MUX, 74LCX157 260377-001
U305 OPAMP, DUAL, SINGLE SUPPLY 256740-001
U306 XMITTER, DIG, CS8405A, SOIC 254163-001
U402 QUAD 2 CHANNEL MUX, 74LCX157 260377-001
U403 CODEC AUDIO, CS4224, SSOP28 254153-001
U404 QUAD 2 CHANNEL MUX, 74LCX157 260377-001
U405 OPAMP, DUAL, SINGLE SUPPLY 256740-001
U406 XMITTER, DIG, CS8405A, SOIC 254163-001
U501 RECEIVER, SPDIF, CS8415A, SOIC 254193-001
U502 QUAD 2 CHANNEL MUX, 74LCX157 260377-001
U503 DAC, 96KHZ, 3-5V, CS4340-KS 256087-001
U504 OPAMP, DUAL, SINGLE SUPPLY 256740-001
U505 QUAD 2 CHANNEL MUX, 74LCX157 260377-001
U601 ENCODER, VIDEO, DIG, CS4955-CQ 256088-001
U602 VIDEO SW, 2-IN, 3-CH, SSOP16 260344-001
U603 DUAL VIDEO AMP, SSOP-8 254181-001
U604 DUAL VIDEOA MP, SSOP-8 254181-001
U701 INVERTER, 5V, 74VCHU04 258464-001
U703 RESET, SOT-23, MAX809, 2.63V 191158-06
U704 IRCODE, KS88C01532, QFP44 (BOS3) 256143-004
U802 VOLT REG, 3.3V, 3.5A, SMPS 193846-001
U803 VOLT REG, 3.3V, 3.5A, SMPS 193846-001
U805 COUNTER, BINARY, 8-BIT 256115-001
U806 VOLT REG, POS, 2.5V, 1.0A, LDO 258495-001
VR1 VOLT REG, POS, 8.0V, SOT-89 258430-W8R0

Bose AV28 Specifications

General

Type	DVD player
Progressive Scan	Yes
Remote Control	Yes
Upscaling	No
Playable Media Format	DVD, CD, MP3
Video Output	Component, Composite, S-Video
Audio Output	Digital Optical, Digital Coaxial
