Bose AV28 User Manual

53
Main PCB 260318-0
Electrical Part List
(Transistors)
Reference
Designator
Description Part Number Note
D304 1N5232, ZENER, 5.6V, 225 mW 135247-5232
D305 BAV99, SOT23 147239
D306 1N5232, ZENER, 5.6V, 225 mW 135247-5232
D401 BAV99, SOT23 147239
D402 BAV99, SOT23 147239
D403 BAV99, SOT23 147239
D501 BAV99, SOT23 147239
D502 BAV99, SOT23 147239
D503 BAV99, SOT23 147239
D504 BAV99, SOT23 147239
D601 BAV99, SOT23 147239
D602 BAV99, SOT23 147239
D603 BAV99, SOT23 147239
D604 BAV99, SOT23 147239
D605 BAV99, SOT23 147239
D606 BAV99, SOT23 147239
D703 BAV99, SOT23 147239
D704 BAV99, SOT23 147239
D705 BAV99, SOT23 147239
D706 SHOTTKY, BAT42W, SOD-123 196984-002
D707 DUAL, SOT-23, BAW56 180738
D801 SB560 254110-005
D803 SCHOTTKY, 40V, 3A, SMB 193847-001
D1000 BAV99, SOT23 147239
D1002 56107, IR EMITTING 256733-002
D1003 56107, IR EMITTING 256733-002
D1004 56107, IR EMITTING 256733-002
D1005 56107, IR EMITTING 256733-002
(Diodes continued)
Reference
Designator
Description Part Number Note
Q101 SOT-23 260354-001
Q103 2SA1521, P, SOT, 2.2K 180789
Q105 2SA1521, P, SOT, 2.2K 180789
Q106 NPN, SOT, 47K 146817
Q201 NPN, SOT, 47K 146817
Q202 SOT-23 260354-001
Q203 NPN, SOT, 47K 146817
Q204 SOT-23 260354-001
Q205 NPN, SOT, 2SC4695 148770
Q206 NPN, SOT, 2SC4695 148770
Q207 PNP, SOT, 47K 146818
Q210 NPN, SOT, 47K 146817
Q211 NPN, SOT, 47K 146817
Q212 PNP, SOT, 47K 146818
Q213 PNP, SOT, 47K 146818
Q214 PNP, SOT, 47K 146818
Q300 NPN, SOT, 2SC4695 148770
Q301 NPN, SOT, 2SC4695 148770
Q302 PNP, SOT, 47K 146818
