52
Main PCB 260318-0
Electrical Part List
(Diodes)
(Capacitors continued)
Reference
Designator
Description Part Number Note
C809 2200pF, 0603, X7R, 50V 191470-222
C812 .047uF, 0603, X7R, 25V, 5% 196999-473
C813 .1uF, 0805, X7R, 10%, 25V 181264-104
C814 .047uF, 0603, X7R, 25V, 5% 196999-473
C815 .1uF, 0805, X7R, 10%, 25V 181264-104
C816 680pF, 0603, X7R, 50V 191470-681
C819 0.47uF, 1812, X7R, 50V, 20% 258418-4743
C820 820pF, 0603, X7R, 50V 191470-821
C821 0.47uF, 1812, X7R, 50V, 20% 258418-4743
C822 0.47uF, 1812, X7R, 50V, 20% 258418-4743
C824 0.47uF, 1812, X7R, 50V, 20% 258418-4743
C828 1000uF, EL, 105, 25V, 20% 258490-102B25E
C832 1000uF, EL, 105, 25V, 20% 258490-102B25E
C837 .047uF, 0603, X7R, 25V, 5% 196999-473
C838 .047uF, 0603, X7R, 25V, 5% 196999-473
C839 330uF, EL, SMD, 105, 10V, 20% 256772-331A
C840 .047uF, 0805, X7R, 50V, 10% 133623-473
C841 .047uF, 0805, X7R, 50V, 10% 133623-473
C842 .047uF, 0805, X7R, 50V, 10% 133623-473
C843 .047uF, 0805, X7R, 50V, 10% 133623-473
C844 .047uF, 0603, X7R, 25V, 5% 196999-473
C845 .047uF, 0603, X7R, 25V, 5% 196999-473
C846 .047uF, 0805, X7R, 50V, 10% 133623-473
C847 .047uF, 0805, X7R, 50V, 10% 133623-473
C848 680pF, 0603, X7R, 50V 191470-681
C849 3.9nF, 0603, X7R, 25V, 5% 196999-392
C1001 22uF, EL, 85, 20%, 16V 177902-220C
Reference
Designator
Description Part Number Note
D1 SHOTTKY, BAT42W, SOD-123 196984-002
D2 SHOTTKY, BAT42W, SOD-123 196984-002
D7 BAV99, SOT23 147239
D8 BAV99, SOT23 147239
D100 BAV99, SOT23 147239
D101 BAV99, SOT23 147239
D102 BAV99, SOT23 147239
D103 BAV99, SOT23 147239
D104 BAV99, SOT23 147239
D105 BAV99, SOT23 147239
D201 SOT, MMBD914LT1 148582
D202 BAV99, SOT23 147239
D203 BAV99, SOT23 147239
D204 BAV99, SOT23 147239
D205 BAV99, SOT23 147239
D206 DUAL, SOT-23, BAW56 180738
D207 BAV99, SOT23 147239
D208 BAV99, SOT23 147239
D301 BAV99, SOT23 147239
D302 BAV99, SOT23 147239
