Bose AV28 User Manual

51
(Capacitors continued)
Main PCB 260318-0
Electrical Part List
Reference
Designator
Description Part Number Note
C641 1uF, TANT, 35V, 1411, 20% 188588-105
C642 1uF, TANT, 35V, 1411, 20% 188588-105
C643 1uF, TANT, 35V, 1411, 20% 188588-105
C644 100pF, 0603, COG, 50V, 5% 188454-101
C645 100pF, 0603, COG, 50V, 5% 188454-101
C646 100pF, 0603, COG, 50V, 5% 188454-101
C647 100pF, 0603, COG, 50V, 5% 188454-101
C648 100pF, 0603, COG, 50V, 5% 188454-101
C649 100pF, 0603, COG, 50V, 5% 188454-101
C650 1uF, TANT, 35V, 1411, 20% 188588-105
C651 1uF, TANT, 35V, 1411, 20% 188588-105
C701 .047uF, 0603, X7R, 25V, 5% 196999-473
C702 390pF, 0603, COG, 50V 188454-391
C704 30pF, 0603, COG, 50V, 5% 188454-300
C705 390pF, 0603, COG, 50V 188454-391
C706 .047uF, 0603, X7R, 25V, 5% 196999-473
C707 30pF, 0603, COG, 50V, 5% 188454-300
C708 390pF, 0603, COG, 50V 188454-391
C709 .047uF, 0603, X7R, 25V, 5% 196999-473
C710 .047uF, 0603, X7R, 25V, 5% 196999-473
C711 4.7nF, 0603, X7R, 25V, 5% 196999-472
C712 4.7nF, 0603, X7R, 25V, 5% 196999-472
C713 4.7nF, 0603, X7R, 25V, 5% 196999-472
C714 4.7nF, 0603, X7R, 25V, 5% 196999-472
C716 4.7nF, 0603, X7R, 25V, 5% 196999-472
C717 4.7nF, 0603, X7R, 25V, 5% 196999-472
C718 4.7nF, 0603, X7R, 25V, 5% 196999-472
C719 4.7nF, 0603, X7R, 25V, 5% 196999-472
C720 4.7nF, 0603, X7R, 25V, 5% 196999-472
C721 4.7nF, 0603, X7R, 25V, 5% 196999-472
C722 4.7nF, 0603, X7R, 25V, 5% 196999-472
C723 4.7nF, 0603, X7R, 25V, 5% 196999-472
C724 4.7nF, 0603, X7R, 25V, 5% 196999-472
C725 4.7nF, 0603, X7R, 25V, 5% 196999-472
C726 4.7nF, 0603, X7R, 25V, 5% 196999-472
C727 4.7nF, 0603, X7R, 25V, 5% 196999-472
C728 4.7nF, 0603, X7R, 25V, 5% 196999-472
C729 4.7nF, 0603, X7R, 25V, 5% 196999-472
C730 .047uF, 0603, X7R, 25V, 5% 196999-473
C733 1000pF, 0603, X7R, 50V 191470-102
C734 1000pF, 0603, X7R, 50V 191470-102
C735 .047uF, 0603, X7R, 25V, 5% 196999-473
C736 .047uF, 0603, X7R, 25V, 5% 196999-473
C737 100pF, 0603, COG, 50V, 5% 188454-101
C739 .047uF, 0603, X7R, 25V, 5% 196999-473
C740 .047uF, 0603, X7R, 25V, 5% 196999-473
C741 .047uF, 0603, X7R, 25V, 5% 196999-473
C742 2.2uF, 1206, X7R, 10V, 20% 260361-2253
C801 330uF, EL, 105, 50V, 20% 258490-331B24H
C803 330uF, EL, 105, 50V, 20% 258490-331B24H
C805 0.1uF, 0805, X7R, 50V, 10% 133624
C806 0.1uF, 0805, X7R, 50V, 10% 133624
C808 2200pF, 0603, X7R, 50V 191470-222

Bose AV28 Specifications

General

Type	DVD player
Progressive Scan	Yes
Remote Control	Yes
Upscaling	No
Playable Media Format	DVD, CD, MP3
Video Output	Component, Composite, S-Video
Audio Output	Digital Optical, Digital Coaxial
