Bose AV28 User Manual

43
(Resistors continued)
Main PCB 260318-0
Electrical Part List
Reference
Designator
Description Part Number Note
R304 10K, 0603, .1W, 1% 191465-1002
R305 10K, 0603, .1W, 1% 191465-1002
R306 100 OHM, 0603, .1W, 5% 199403-101
R307 100 OHM, 0603, .1W, 5% 199403-101
R308 22 OHM, 0603, .1W, 5% 199403-220
R309 100 OHM, 0603, .1W, 5% 199403-101
R312 100 OHM, 0603, .1W, 5% 199403-101
R313 22 OHM, 0603, .1W, 5% 199403-220
R314 22 OHM, 0603, .1W, 5% 199403-220
R315 2.0 OHM, 0603, SMD, 100mW 199403-2R0
R316 100 OHM, 0603, .1W, 5% 199403-101
R317 100 OHM, 0603, .1W, 5% 199403-101
R318 100 OHM, 0603, .1W, 5% 199403-101
R319 14 OHM, 0603, .1W, 1% 191465-1402
R320 14 OHM, 0603, .1W, 1% 191465-1402
R321 14 OHM, 0603, .1W, 1% 191465-1402
R322 14 OHM, 0603, .1W, 1% 191465-1402
R323 100 OHM, 0603, .1W, 5% 199403-101
R324 100 OHM, 0603, .1W, 5% 199403-101
R325 14 OHM, 0603, .1W, 1% 191465-1402
R326 14 OHM, 0603, .1W, 1% 191465-1402
R327 3.24K, 0603, .1W, 1% 191465-3241
R328 3.24K, 0603, .1W, 1% 191465-3241
R329 3.24K, 0603, .1W, 1% 191465-3241
R330 3.24K, 0603, .1W, 1% 191465-3241
R331 14 OHM, 0603, .1W, 1% 191465-1402
R332 14 OHM, 0603, .1W, 1% 191465-1402
R333 432 OHM, 0603, 100MW, 1% 191465-4320
R334 432 OHM, 0603, 100MW, 1% 191465-4320
R335 100K, 0603, .1W, 5% 199403-104
R336 100K, 0603, .1W, 5% 199403-104
R337 49.9 OHM, 0603, .1W, 1% 191465-49R9
R338 10K, 0603, .1W, 5% 199403-103
R339 10K, 0603, .1W, 5% 199403-103
R340 JUMPER, CHIP, 0603 196042
R341 JUMPER, CHIP, 0603 196042
R342 330 OHM, 0603, .1W, 5% 199403-331
R343 4.7K, 0603, .1W, 5% 199403-472
R344 4.7K, 0603, .1W, 5% 199403-472
R345 4.7K, 0603, .1W, 5% 199403-472
R346 432 OHM, 0603, 100MW, 1% 191465-4320
R347 191 OHM, 0603, .1W, 1% 191465-1910
R348 432 OHM, 0603, 100MW, 1% 191465-4320
R349 191 OHM, 0603, .1W, 1% 191465-1910
R350 4.7K, 0603, .1W, 5% 199403-472
R351 100 OHM, 0603, .1W, 5% 199403-101
R352 1.0K, 0603, .1W, 1% 191465-1001
R353 100 OHM, 0603, .1W, 5% 199403-101
R354 332 OHM, 0603, .1W, 1% 191465-3320
R401 1.33K, 0603, 100mW, 1% 191465-1331
R402 1.33K, 0603, 100mW, 1% 191465-1331
R403 10K, 0603, .1W, 1% 191465-1002
R404 10K, 0603, .1W, 1% 191465-1002
