Bose AV28 User Manual

44
(Resistors continued)
Main PCB 260318-0
Electrical Part List
Reference
Designator
Description Part Number Note
R405 100 OHM, 0603, .1W, 5% 199403-101
R406 100 OHM, 0603, .1W, 5% 199403-101
R407 100 OHM, 0603, .1W, 5% 199403-101
R410 100 OHM, 0603, .1W, 5% 199403-101
R411 100 OHM, 0603, .1W, 5% 199403-101
R412 2.0 OHM, 0603, SMD, 100mW 199403-2R0
R413 100 OHM, 0603, .1W, 5% 199403-101
R414 100 OHM, 0603, .1W, 5% 199403-101
R415 14 OHM, 0603, .1W, 1% 191465-1402
R416 14 OHM, 0603, .1W, 1% 191465-1402
R417 14 OHM, 0603, .1W, 1% 191465-1402
R418 14 OHM, 0603, .1W, 1% 191465-1402
R419 100 OHM, 0603, .1W, 5% 199403-101
R420 100 OHM, 0603, .1W, 5% 199403-101
R421 14 OHM, 0603, .1W, 1% 191465-1402
R422 14 OHM, 0603, .1W, 1% 191465-1402
R423 3.24K, 0603, .1W, 1% 191465-3241
R424 3.24K, 0603, .1W, 1% 191465-3241
R425 3.24K, 0603, .1W, 1% 191465-3241
R426 3.24K, 0603, .1W, 1% 191465-3241
R427 14 OHM, 0603, .1W, 1% 191465-1402
R428 14 OHM, 0603, .1W, 1% 191465-1402
R429 1.0K, 0603, .1W, 1% 191465-1001
R430 1.0K, 0603, .1W, 1% 191465-1001
R431 100K, 0603, .1W, 5% 199403-104
R432 100K, 0603, .1W, 5% 199403-104
R433 49.9 OHM, 0603, .1W, 1% 191465-49R9
R434 10K, 0603, .1W, 5% 199403-103
R435 10K, 0603, .1W, 5% 199403-103
R436 JUMPER, CHIP, 0603 196042
R437 JUMPER, CHIP, 0603 196042
R438 330 OHM, 0603, .1W, 5% 199403-331
R439 1.0K, 0603, .1W, 1% 191465-1001
R440 100 OHM, 0603, .1W, 5% 199403-101
R441 332 OHM, 0603, .1W, 1% 191465-3320
R501 75 OHM, 0603, 0.1W, 5% 199403-750
R502 75 OHM, 0603, 0.1W, 5% 199403-750
R503 75 OHM, 0603, 0.1W, 5% 199403-750
R504 75 OHM, 0603, 0.1W, 5% 199403-750
R505 75 OHM, 0603, 0.1W, 5% 199403-750
R506 75 OHM, 0603, 0.1W, 5% 199403-750
R507 75 OHM, 0603, 0.1W, 5% 199403-750
R508 75 OHM, 0603, 0.1W, 5% 199403-750
R509 2.2K, 0603, .1W, 5% 199403-222
R510 3.3K, 0603, .1W, 5% 199403-332
R511 47K, 0603, .1W, 5% 199403-473
R512 100 OHM, 0603, .1W, 5% 199403-101
R513 909 OHM, 0603, .1W, 1% 191465-9090
R514 100 OHM, 0603, .1W, 5% 199403-101
R515 100 OHM, 0603, .1W, 5% 199403-101
R516 100 OHM, 0603, .1W, 5% 199403-101
R517 100 OHM, 0603, .1W, 5% 199403-101
R522 10K, 0603, .1W, 1% 191465-1002

Bose AV28 Specifications

General

Type	DVD player
Progressive Scan	Yes
Remote Control	Yes
Upscaling	No
Playable Media Format	DVD, CD, MP3
Video Output	Component, Composite, S-Video
Audio Output	Digital Optical, Digital Coaxial
