Bose B2000

10
4. Installation
4.7 Link ing amplifiers
Each amplifier channel is provided with a 3-pin XLR connector marked Link which
allows the input signals to be linked to further amplifiers etc. The pin connections a re
the same as for the input .
4.8 B ridged m ono operation
For bridged mono operation connection should be made to channel A input only. Set
t he rear panel bridge switch to the bridged mono position for bridged mono operation .
The output should be taken from the bridged output Speakon connector
When using a B 1500 or B2000 in bridged mono with a BOSE
®
EQ card, only 1 card
should be fitted into the channel A EQ connector socket located inside the amplifi er.
For f urther details see chapter 7: Bose® EQ cards.
