Bose B2000

17
8 . Technical Specification
TECHNICAL SPECIFICATION B 1500
POWER OUTPUT:
Continuous output power,
both channels driven:
Power values measur ed at 230Vac
450 Watts per channel into 8 from
20Hz to 20 kHz, with no more than
0.03% THD
715 Watts per channel into 4 from
20Hz to 20 kHz , with no more than
0.03% THD
1025 Watts per channel into 2 from
20H z to 20 kHz, with no more than
0.03% THD
Bridged - mono operation:
1430 watts into 8 from 20Hz to 20
kHz, with less than 0.03% THD
2050 watts into 4 from 20Hz to 20
kHz, with less than 0.03% THD
Frequency response:
20Hz to 20 kHz (±0.5dB)
Input impedance:
20k balanced
Sensitivity:
1.38V rms for rated power into
4 (+5dBu)
Gain:
32 dB
THD 4 :
1 kHz <0.008%
20Hz to 20 kHz <0.03%
Power requirements:
230VAC/50 - 60Hz (Europe & UK
Ampl ifier set at 240Vac )
CMRR:
> 90dB
Fusing:
10 Amp S low - blow
(230V/50Hz)
Hum & noise
- 105dB
Damping factor 1 kHz:
>400 (at 8 )
Size (H x W x D):
88 mm x 482 mm x 428 mm
Net weight:
20 kg
TECHNICAL SPECIFICATION B2000
POWER OUTPUT:
Continuous output power,
both channels driven:
Power values measur ed at 230Vac
560 watts per channel into 8 from
20Hz to 20 kHz, with no more than
0.03% THD
925 Watts per channel into 4 from
20Hz to 20 kHz, with no more than
0.03% THD
13 00 Watts per channel in to 2 from
20Hz to 20 kHz, with no more than
0.03% THD
Bridged - mono operation:
185 0 watts into 8 from 20Hz to 20
kHz, with less than 0.03% THD
26 00 watts into 4 from 20Hz to 20
kHz, with less than 0.03% THD
Frequency response:
20Hz to 20 kHz (±0.5dB)
Input impedance:
20k balanced
Sensitivity:
1.75V rms for rated power into
4 (+7dBu)
Gain:
32 dB
THD 4 :
1 kHz <0.008%
20Hz to 20 kHz <0.03%
Power requirements:
230VAC/50 - 60Hz (Europe & UK
Amplifier set at 240Vac )
CMRR:
> 90dB
Fusing:
15 Amp Trip
(230V/50Hz)
Hum & noise
- 105dB
Damping factor 1 kHz:
>400 (at 8 )
Size (H x W x D):
88 mm x 482 mm x 428 mm
Net weight:
25 kg
