User Control Interfaces
ControlSpace
®
wall-mounted controls are easy to integrate and provide elegant, easy to operate control surfaces for end users.
The following interfaces can be used with the ESP-00 II engineered sound processor:
Figure 2. CC-64 Control Center
12
• ControlSpace CC-64 control center (PC 041760) (Figure 2)
Network control of any Bose
®
networkable hardware.
• ControlSpace CC-16 zone controller (PC 041761)
Uses CC-16 port. Up to 15 devices can be used with any ESP engineered sound processor.
• ControlSpace CC-4 room controller (PC 042023)
Uses GPI port: Requires 5 control inputs and one ground termination.
