Bose F1 812 User Manual

6 - English
Introduction
Using the Flexible Array
You can shape the coverage pattern by moving the position of the top and bottom array. The array position is held in
place by magnets that trigger internal sensors that adjust EQ according to array shape.
Adjusting the array
Pushing the array in Pulling the array out
Four coverage patterns
Straight pattern
Pull top and bottom array out
J pattern
Pull top array out, push bottom array in.
Reverse-J pattern
Push top array in, pull bottom array out.
C pattern
Push top and bottom array in.

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
