Bose F1 812 User Manual

8 - English
Setting Up the System
Using the F1 Model 812 with the F1 Subwoofer
The built-in loudspeaker stand is stored in the rear of the subwoofer. Setting up the F1 Model 812 Loudspeaker with
the F1 Subwoofer is easy:
1. Remove the built-in speaker stand from the back of the F1 Subwoofer and insert it into the stand slots.
Built-in speaker
stand
Stand slots
2. Lift the F1 Model 812 Loudspeaker and place it on the stand.

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
