Bose FREESPACE BMA-125 User Manual

33
230V Tone/Volume/Equalizer PCB
Resistors
Reference
Designator
Description Part Number See Note
R49 3.09KΩ, 1%,
1/4W, MF
185516
R50 825KΩ, 1%, 1/4W,
MF
185517
R51 82.5KΩ, 1%,
1/4W, MF
185518
R52, 54 8.25KΩ, 1%,
1/4W, MF
185519
R59 7150Ω, 1/4W 185520
Reference
Designator
Description Part Number See Note
C1, 4, 26 4.7 µF, 50V, ELCT
NP
185521
C2, 21 220 PF, 50V,
CER, 20%
185463
C3, 5, 6, 41 47 µF, 25V, ELCT
RDL
185523
C7, 43, 46, 47 .01 µF, 50V, CER,
20%
185455
C8 470 PF, 50V,
CER, 20%
185461
C9 56 PF, 50V, CER,
20%
185526
C10, 11, 15, 16,
27, 28, 32-35
.1 µF, 50V, CER,
20%
185527
C12, 14, 18 220 µF 185528
C13 4.7 µF, 50V, ELCT
RDL
185529
C17 5 PF, 1KV, CER,
20%
185530
C19, 20 .015 µF, 50V,
CER, 20%
185531
C22 22 PF, 1KV, CER,
10%
185532
C23, 24, 25 2200 PF, 50V,
CER, 20%
185533
C29, 30 .0056 µF 185534
C31 .047 µF 185535
C36 .068 µF 185536
Capacitors
