34
Reference
Designator
Description Part Number See Note
C37, 38 .1 µF 185537
C39 .0068 µF 185538
C40 330 PF, 5%, CER 185539
C42 3900 PF, 50V,
CER, 20%
185540
C45 100 PF, 50V, CER 185453
Reference
Designator
Description Part Number See Note
Q1 2N5086 185470
Q3 2N3904 185543
Reference
Designator
Description Part Number See Note
U1, 2, 4, 5 LM833 185474
U6 DG211CJ 185545
Reference
Designator
Description Part Number See Note
CR1, CR15, CR18 SIGNAL 185546
CR16, 17 ZENER, 18V 185547
230V Tone/Volume/Equalizer PCB
Capacitors
Transistors
Integrated Circuits
Diodes
