Bose L1 Pro8 Service Manual

11
Main Part List
L1 Pro8 Power Stand (see Figure 2)
Item
Number
Description Bose Material
Number
Vendor Part
Number
Notes
34 GRILLE ASSY, POWER STAND, SVCE 861200-011S T130207400100
35 SILICON FOAM, 25 DEGREE, FRONT - T180200015750
36 CABLE, TW1+EQ, 6PIN - T641700169000
37 ENCLOSURE, LEFT - T100422600100
38 WADDING, FR-W0025, WHITE - T182700002480
39 ENCLOSURE, TOP - T100422900100
40 COVER SEAL, BLACK - T100424300100
41 PE FOAM, ADHESIVE, BLACK, DS11 K - T180500031060
42 HANDLE, TOP - T100403900100
43 EVA, 38 DEGREE, ADHESIVE, BLACK,
DS11 K
- T180500032720
44 EVA, 38 DEGREE, ADHESIVE, BLACK,
DS11 K
- T180500032710
45 NUT, M8 - T181000000660
46 SCREW, T3.5XL14 - T15335142F610
47 SCREW, M8XL30 - T15180302F410
48 PCB SUBASSY, VOLUME, SVCE 861359-001S T910000074760
49 PORON, ADHESIVE, BLACK, DS11 K 843134-0110 T180500033870
50 BRACKET, VOLUME - T100402800100
51 PE FOAM, ADHESIVE, BLACK, DS11 K - T180500031000
52 INLAY, BOTTOM, BACK - T180700009350
53 RUBBER RING, 50 DEGREE, BLACK - T180200016500
54 KNOB, VOLUME 841657-0110 T100403800100

Bose L1 Pro8 Specifications

General

Tweeter	Yes
Amplifier	Built-in
Speaker type	-
Amplifier class	D
Number of drivers	8
Number of speakers	1
Woofer diameter (imperial)	13 \
Tweeter diameter (imperial)	2 \
Frequency range	- Hz
RMS rated power	300 W
Speakers RMS power	60 W
Sound pressure level (max)	118 dB
Wi-Fi	No
AUX in ports	2
Connectivity technology	Wired & Wireless
Type	Freestanding Public Address (PA) system
Control type	Buttons, Rotary
Product type	2.1 portable speaker system
Mounting type	Floor
Product color	Black
Volume control	Rotary
Number of mixer channels	3 channels
Power source type	AC

Weight and Dimensions

Depth	440 mm
Width	318 mm
Height	2005 mm
Weight	18000 g
