Bose L1 Pro8

14
Main Part List
L1 Pro8 I/O Panel Assy (see Figure 3)
Item
Number
Description Bose Material
Number
Vendor Part
Number
Notes
33 LIGHT GUIDE, POLARITY - T100402300100
34 BUTTON, SELECTION, PC+ABS - T100402900100
35 BUTTON, MUTE, MILK - T100403300200
36 NON WOVEN, ADHESIVE, BLACK,
DS11
- T182900003180
37 SCREW, T3XL12, .3P, ZINC+NICKEL - T153301210630
38 SCREW, M3XL10, ZINC+NICKEL - T151301030610-02
39 I/O PANEL, AL1050 - T130202400100
40 PE FOAM, ADHESIVE, BLACK, DS11 K - T180500031160
41 PLUG, 250VA 10A - T691200007600 3
42 1P, YELLOW\GREEN, 16AWG, UL1015
100MM
- T641700184000
43 SMPS, CONNECT CABLE, 3PIN - T641700169200
44 HEAT SHRINK TUBE, BLACK, OD30X-
L25XT0
- T690200008700
45 NUT, M3.0X0.5PXOD5.5XL2.3, NICKEL
PLATE
- T181000000520
46 NUT, M4XOD8.0XH4.1 0.7P - T181000001240
47 EQ, LIGHT GUIDE, MILK - T100402200100
48 BUTTON, PHANTOM, BLACK - T100403400100
49 USB, BRACKET, SPCC - T130202800100
50 CONN, IO, 3POLE, XLR, P, HARD
GOLD
- T710200019600
51 NON WOVEN, ADHESIVE, BLACK,
DS11
- T182900003060
52 PE FOAM, ADHESIVE, BLACK, DS11 K - T180500031090
53 PE FOAM, ADHESIVE, BLACK, DS11 K - T180500031140
54 FIRE BOX, PC+ABS, BLACK - T100402700100
55 PE FOAM, ADHESIVE, BLACK, DS11 K - T180500031100
56 SPONGE, YU356A, ADHSIVE 3212 - T180500032730
57 BRIDGE, HEATSINK, AL6063 - T130203000100
58 ASSY, PCBA, PWR SUPP-AMP, SVCE 861372-001S T910000070290
59 U CLIP, SILICONE - T180200016470
60 SCREW, M3.0XL7, SILVER ZINC+NICK-
EL
- 847867-M03M07
PTA3
61 HEATSINK, AL1050 T130202700100
NA GAP FILLER,THERMAL,ONE PART,
55CC
749859-0020 -
