Bose L1 Pro8

21
Reference Designator Description Material Number Note
R35, R53
RES, THICK FILM, 0603, 0.1W, 1%, 28K 857326-0137
R36, R43, R57, R65,
R198A, R198B, R207A,
R207B
RES, THICK FILM, 0805, 0.125W, 1%, 100
OHM
857326-0186
R364, R195A, R195B,
R202A, R202B, R208A,
R208B, R209A, R209B,
R211A, R211B, R247A,
R247B, R252A, R252B,
R253A, R253B, R257A,
R257B, R260A, R260B
RES, THICK FILM, 0603, 0.1W, 1%, 1K 857326-0092
R37, R50, R54, R68
RES, THICK FILM, 0603, 0.1W, 1%, 14K 857326-0106
R375, R379, R383
RES, THICK FILM, 0603, 0.1W, 1%, 560 OHM 857326-0165
R38, R41
RES, THICK FILM, 0603, 0.1W, 1%, 20K 857326-0120
R39, R45, R55, R62
RES, THICK FILM, 0603, 0.1W, 1%, 120K 857326-0102
R397, R425
RES, THICK FILM, 0402, 0.063W, 1%, 4.7K 857326-0070
R4, R15, R88, R99, R114,
R117, R130, R277, R292,
R370, R385, R400, R424,
R256A, R256B, R262A,
R262B, R291A, R291B
JUMPER, CHIP, 0603 857326-0218
R40, R46, R56, R63, R105,
R217A, R217B, R220A,
R220B, R225A, R225B,
R239A, R239B, R241A,
R241B, R243A, R243B
RES, THICK FILM, 0603, 0.1W, 1%, 10 OHM 857326-0181
R406
RES, THICK FILM, 0603, 0.1W, 1%, 68.1 OHM 857326-0173
R413
RES, THICK FILM, 0603, 0.1W, 1%, 750 OHM 857326-0174
R42, R49, R59, R67, R163,
R166, R210A, R210B,
R232A, R232B
RES, THICK FILM, 0603, 0.1W, 1%, 2.2K 857326-0127
R431
RES, THICK FILM, 0402, 0.063W, 1%, 2.2K 857326-0044
R44, R47, R60, R64, R281,
R391-R392, R418, R212A,
R212B, R218A, R218B,
R228A, R228B, R244A,
R244B, R249A, R249B,
R261A, R261B
RES, THICK FILM, 0603, 0.1W, 1%, 4.7K 857326-0155
R462-R463, R464A, R464B
RES, THICK FILM, 0402, 0.063W, 1%, 1.5K 857326-0030
R466A, R466B, R467A,
R467B
RES, THICK FILM, 0402, 0.063W, 1%, 360
OHM
857326-0059
R48, R66, R80, R86, R159,
R233A, R233B, R74C,
R74D, R77C, R77D
RES, THICK FILM, 0603, 0.1W, 1%, 47K 857326-0156
R51, R69
RES, THICK FILM, 0603, 0.1W, 1%, 2.4K 857326-0132
R52, R70, R191, R236A,
R236B
RES, THICK FILM, 0402, 0.063W, 1%, 1K 857326-0020
MAIN-I/O PCB PARTS LIST
Resistors (continued)
