Bose L1 Pro8

27
MAIN-I/O PCB PARTS LIST
Miscellaneous
Reference Designator Description Material Number Note
SW1-SW2, SW4, SW6-
SW10
SWITCH, TACT, 12V, 50mA, 250gf 850862-0010
SW3 SWITCH, TACT, 15V, 20mA, 320GF 854394-0010
T1 TRANSFORMER, AUDIO, DIGITAL, DIL, 1mH 856463-0010
USB1 CONN, IO, TYPE C, 24P, R, SMT, RA,
TMOUNT, CH2.2
853416-0010
CN1 CONN, RECP, 1.27mm C, 16P, 2R, R, SMT, ST 847826-0016
J1 CONN, RECP, 1.27mm C, 10P, 2R, R, SMT, ST 847826-0010
J16 CONN, HDR, 1.5mm C, 11P, 1R, P, SMT, ST,
BEIGE
847746-0110
J17 CONN, HDR, 1.5mm C, 10P, 1R, P, SMT, ST,
BEIGE
847746-0100
J18 CONN, HDR, 1.5mm C, 8P, 1R, P, SMT, ST,
BEIGE
847746-0080
J19A, J19B CONN, IO, XLR, 3POLE, ST, R, PCB Mount 850870-0010
J22 CONN, RECP, 2.54mm C, 28P, 2R, R, SMT,
ST, BL, Au
847748-0028
J3 CONN, IO, 3.5mm EAR PHONE JACK, TH,
31.1L
852736-0010
J4 CONN, IO, 6.35MM STERIO JACK, R, ST, PCB
MOUN
849858-0010
J5 CONN, IO, 3POLE XLR, P, Sel Gold 763327-0120
