Introduction
pro.Bose.com
14 - Installation Guide
Please complete and retain for your
records.
Serial number: _________________
Model number: _________________
Product Overview
The Bose Professional Panaray® MSA12X is a digital beam-steering loudspeaker that enables improved room
aesthetics, with outstanding vocal intelligibility and tonal consistency. The proprietary Articulated Array®
transducer configuration allows wide, 160° horizontal coverage throughout the room, and MSA12X’s modular
design allows building of vertical arrays using one (1) to three (3) units. Dante® digital audio network interface
comes standard for connection with other Dante-enabled products over Ethernet-based networks.
Product Features
• Digital beam-steering line array column loudspeaker with onboard DSP and 600 watts (12 x 50 W) of
amplification
• Family sound profile with the Panaray MA12EX Loudspeaker
• Twelve (12) x 2.25-inch full-range transducers with 80 Hz – 18 kHz frequency range
• Dante® digital audio network interface and line-level analog input
• Articulated Array® configuration allows wide, 160° horizontal coverage
• Modular design allows building vertical arrays using 1-3 units
• Multiple algorithms for beam steering control – designers can optimize consistency of coverage, tonal balance,
and maximum SPL per job
• Supports independent level and EQ control of 2 separate beams per array
• Integrated mounting bracket allows up 90° of horizontal yaw adjustment
• Advanced steering and acoustic coverage prediction using Bose Modeler® software
• System setup, control and monitoring with Bose ControlSpace® Designer™ software
• Available in black or white finish
Package Contents
The MSA12X loudspeaker package contains the following:
One (1) MSA12X loudspeaker module One (1) 3-pin Euroblock connector
Two (2) wall/loudspeaker bracket sets Eight (8) M6 flanged head bolts
One (1) interconnect bracket Four (4) flat washers
One (1) yaw bracket Four (4) double-sided washer tape rings
Three (3) power interconnect cables (region-specific) Four (4) M6 flanged nuts
One (1) power cable Twelve (12) zip ties
One (1) LVDS audio/control expansion cable (RJ-50) Twelve (12) self-tapping screws
One (1) Bose logo nameplate
