CLASSROOM
Portable
music player
Wireless
mic
La
ptop
PS604
ESP-880
CC-64
Screen L/R
400 W
Ceiling
160 W
AUTO STANDBY
SENSITIVITY
GLOBAL OUT
OUTPUT 1
OUTPUT 2
OUTPUT 3
OUTPUT 4
CONFIG
12 dBu
100V
Low Z
4 dBu
70V
Hi Z
Low ZHi Z
ON
Low Z
SOFTWARE
OFF
Hi Z
REAR
Low ZHi Z
EQ Dials
Flat Flat Flat
DIP Switch Settings
Set 70/100V as necessary
All information subject to change without notice.
© 2016 Bose Corporation
All trademarks are those of their respective owners.
Classroom Example
Requirements:
• Low-Z and Hi-Z loudspeakers in one zone
• Wall-mounted volume control and source selection
• Three audio sources: a portable music player, laptop and wireless mic
Solution:
Inputs Outputs Control
Device Mode Amp Zones Mode Loudspeakers Z Power/Ch Level Source
ESP-880
Mono &
Stereo
PS604 1
Mono &
Stereo
(1) RMU108 LZ 200 W
CC-64 CC-64
(1) RMU108 LZ 200 W
(4) DS 40 @ 40 W HZ 160 W
PowerShare Editor Software Settings:
None required, all settings made in
the ESP-880.
Amplifier output
Audio input
Zone control
