Specifications, Asymmetrical Versions
PART LIST NOTES
1. The individual parts located on the PCBs are listed in the Electrical Part List.
2. This part is referenced for informational purposes only. It is not stocked as a repair part.
Refer to the next higher assembly for a replacement part.
3. This part is critical for safety purposes. Failure to use a substitute replacement with
the same safety characteristics as the recommended replacement part might create shock,
fire and/or other hazards.
Dimensions
ModelRM283505  16.9x39.1x23.6in(42 8x993x598mm)
ModelRM284505  16.9x39.1x23.6in(42 8x993x598mm)
ModelRM286005  16.9x39.1x23.6in(42 8x993x598mm)
ModelRM352805  16.9x39.1x23.6in(42 8x993x598mm)
ModelRM452805  16.9x39.1x23.6in(42 8x993x598mm)
ModelRM602805  16.9x39.1x23.6in(42 8x993x598mm)
ModelRM283510  17.9x39.1x23.6in(45 5x993x598mm)
ModelRM284510  17.9x39.1x23.6in(45 5x993x598mm)
ModelRM286010  17.9x39.1x23.6in(45 5x993x598mm)
ModelRM352810  17.9x39.1x23.6in(45 5x993x598mm)
ModelRM452810  17.9x39.1x23.6in(45 5x993x598mm)
ModelRM602810  17.9x39.1x23.6in(45 5x993x598mm)
ModelRM284520  20.0x39.1x23.6in(50 9x993x598mm)
ModelRM286020  20.0x39.1x23.6in(50 9x993x598mm)
ModelRM356020  20.0x39.1x23.6in(50 9x993x598mm)
ModelRM452820  20.0x39.1x23.6in(50 9x993x598mm)
ModelRM602820  20.0x39.1x23.6in(50 9x993x598mm)
ModelRM603520  20.0x39.1x23.6in(50 9x993x598mm)
ModelRM286040  24.0x39.1x23.6in(61 0x993x598mm)
ModelRM356040  24.0x39.1x23.6in(61 0x993x598mm)
ModelRM602840  24.0x39.1x23.6in(61 0x993x598mm)
ModelRM603540  24.0x39.1x23.6in(61 0x993x598mm)
NetWeight 123lbs(55.8kg)
ShippingWeight withpalletapproximate ly180lbs(81.6kg)
Mult iple‐ModuleArrayLF(10 "woofer)BandpassPerformance (withEQ)
 2Modu le 4Module 6Module 8Module
TotalPowerHandling,ArrayLFSection 1000W 2000W 3000W 4000W
60HzHigh‐Pa ss
ArrayLFSensitivity,FreeField(SPL/1W@1m) 96d
B
 99dB 101dB 102dB
ArrayLFCalculatedMax. SPL@1m,continuous 126dB 132dB 136dB 138dB
ArrayLFCalculatedMax. SPL@1m,peak 132dB 138dB 142dB 144dB
16
‐
meterArrayLFCa lc ulatedMax.SPL,continuous 102dB 108dB 112dB 114dB
80HzHigh‐Pa ss
ArrayLFSensitivity,FreeField(SPL/1W@1m) 98d
B
 101dB 103dB 104dB
ArrayLFCalculatedMax. SPL@1m,continuous 128dB 134dB 138dB 140dB
ArrayLFCalculatedMax. SPL@1m,peak 134dB 140dB 144dB 146dB
16
‐
meterArrayLFCa lc ulatedMax.SPL,continuous 104dB 110dB 114dB 116dB

