DISASSEMBLY PROCEDURES
Note: Refer to Figure 2 for the following
procedures.
1. Horn Grille Removal
1.1 Remove the six screws (16) that secure
the horn grille (1) to the speaker end panels.
Lift off the grille.
2. Conical Bass Grille Removal
2.1 Remove the four screws (2) that secure
the conical bass grille (3) to the front of the
end panel. Lift off the grille.
3. Side Bass Grille Removal
3.1 Perform procedure 2.
3.2 Remove the four screws (2) that secure
the side bass grille (4) to the end panel. Lift
off the grille.
4. Woofer Removal
4.1 Perform procedure 3.
4.2 Remove the eight screws that secure the
woofer (6) to the bass module cabinet. Lift
out the woofer. Disconnect the two Faston
connectors from the terminals on the back of
the woofer.
5. Input / Output Panel Removal
5.1 On the back of the speaker, remove the
four screws (14) that secure the I/O panel
(13) to the bass modules. Lift the I/O panel
away from the speaker, and unplug the wiring
harness from the PCB assembly.
6. Input / Output PCB Assembly Removal
6.1 Perform procedure 5.
6.2 Unplug the wiring harness that runs from
the PCB to the Neutrik connectors.
6.3 Remove the four screws that secure the
PCB assembly to the standoffs on the I/O
panel. Lift off the PCB assembly.
7. Compression Driver Removal
7.1 Perform procedure 5.
7.2 Disconnect the two wiring harness
Faston connectors from the driver you wish
to replace.
7.3 Remove the two screws that secure the
compression driver to the adapter. Take care
to not lose the screws or the nuts that
secure the driver in place. Lift off the driver.
