MAIN PART LIST
RoomMatch
®
Array Module Loudspeakers (refer to Figure 2)
Item
Number
Description Part Number Qty. Note
1 GRILLE, HORN, METAL, BLK, 5 DEGREE 345921-0510 1
GRILLE, HORN, METAL, BLK, 10 DEGREE 345921-1010 1
GRILLE, HORN, METAL, BLK, 20 DEGREE 345921-2010 1
GRILLE, HORN, METAL, BLK, 40 DEGREE 345921-4011 1
GRILLE, HORN, METAL, BLK, 60 DEGREE 345921-6011 1
2 SCREW, TAPP, 6-13x.5, PAN, XREC/SQ
(WOOFER GRILLE SCREWS)
290294-08 16
3 GRILLE, BASS, CONICAL, BLK, 5 DEG 345273-0510 2
GRILLE, BASS, CONICAL, BLK, 10 DEG 345273-1010 2
GRILLE, BASS, CONICAL, BLK, 20 DEG 345273-2010 2
GRILLE, BASS, CONICAL, BLK, 40 DEG 345273-4010 2
GRILLE, BASS, CONICAL, BLK, 60 DEG 345273-6010 2
4 GRILLE, BASS, SIDE, 5 DEG 345274-0510 2
GRILLE, BASS, SIDE, 10 DEG 345274-1010 2
GRILLE, BASS, SIDE, 20 DEG 345274-2010 2
GRILLE, BASS, SIDE, 40 DEG 345274-4010 2
GRILLE, BASS, SIDE, 60 DEG 345274-6010 2
5 SCREW,M5X0.8, 20MM LG,BUT HEAD,SHCS,BLK 345852-2010 16
6 WOOFER, 10 INCH, SERVICE 323085-0010 2
7 NUT, HEX, M5, THIN, BLK 347307-1210 2
8 BRACKET, INNER RIGHT, SIDE, BLK - 1 2
9 BRACKET, OUTER RIGHT, SIDE, BLK - 1 2
10 SCREW, M5x0.8, 12MM LG, FH SHCS, BLK 345850-1210 10
11 SCREW, M8X1.25, 25MM LG, FLNGD HEX HEAD, BLK 347375-2510 12
12 SCREW, M10x1.5, 30MM LG, HH, FLNG, BLK 345849-3010 4
13 INPUT / OUTPUT PANEL ASSEMBLY 331412-013S 1
14 SCREW, M4x0.7, 8MM LG, PH, XREC, BLK
(I/O PANEL TO BASS MODULES)
345851-0810 4
15 COMPRESSION DRIVER, SERVICE 342658-0010 6
16 SCREW,M5X0.8,30MM LG,FLAT HEAD SHCS,BLK
(HORN GRILLE SCREWS)
345850-3000 6
17 NUT, WELL, M5x0.8 343400-0110 6
18 BRACKET, OUTER LEFT, SIDE, BLK - 1 2
19 BRACKET, INNER LEFT, SIDE, BLK - 1 2
- SCREW, COMPRESSION DRIVER TO ADAPTER 348244-1610 12
- NUT, COMPRESSION DRIVER TO ADAPTER 344149-1110 12
- INPUT / OUTPUT PCB ASSEMBLY, SERVICE 347480-001S 1
- BOLT, INTERMODULE RIGGING 345849-3010 VAR
