10 - ENGLISH
PREPARING THE HEADSET FOR USE
Connecting the control module to the
belt pack
1. Line up the pins on the belt pack connector with the holes in the XLR connector.
2. Press firmly until you hear a click.
XLR connector
Belt pack
Control module
