Bose SoundDock Service Manual

4
SPECIFICATIONS
Electrical
Power Supply Input:
Voltage: 100VAC to 240VAC (universal), 50-60Hz
Current Consumption: 1 A (rms) max for 115VAC
.5 A (rms) max for 230VAC
Power Supply Output:
Voltage: 20V
+/- 1V
Current: 2A (max)
SoundDock
®
Input:
Voltage: ±18VDC-10%, +15%
Current Consumption: 1A (max)
Power Consumption: 36W (max, continuous)
Acoustic
Drivers: 2 - 2.25” Full Range Twiddler™ speakers
Nominal Impedance: 3.6 Ohms
Port Tuning: 80 HZ
Physical Description
Mechanical Specifications: 6.65”H x 11.91”W x 6.48”D (16.89 cm x 30.26 cm x 16.47 cm)
Weight: 4.56 lb (2.1 kg)
Enclosure: Ultrasonically welded PC/ABS plastic

Bose SoundDock Specifications

General

Compatibility	iPod
Product color	Black
Dimensions (WxDxH)	302.6 x 168.9 x 164.7 mm

Weight and Dimensions

Weight	2070 g
