Bose SoundTouch Service Manual

4
Placing the system on the pedestal
The SoundTouch™ pedestal provides the
network connection for the Wave
®
music
system III.
1. Place the SoundTouch pedestal on a flat,
stable surface.
2. Carefully set your Wave
®
music system III
on top of the SoundTouch pedestal.
• Make sure the rear feet of the Wave
®
music
system III fit into the recesses on top of the
SoundTouch pedestal.
• Make sure the Wave
®
music system III sits
flat and the side edges of both units are
aligned.
3. Insert the SoundTouch pedestal cable into
the Bose
®
link connector.
PRODUCT DESCRIPTION (CONT.)
SoundTouch
™
pedestal
Place rear feet
into recesses
®
Adding the system to your Wi-Fi network
Before you can use SoundTouch you must
install the SoundTouch app on a computer
that is on your home network.
Next, you will use the app to connect the
Wave
®
SoundTouch music system to the
network. The app guides you through the
setup process.
Make sure you follow the instructions on your
computer.
Note: If you have already set up SoundTouch
for another system, just launch the app and
click Explore > Setings > Systems > Add
System to add another system.
Installing the SoundTouch app
1. From a computer that is on your Wi-Fi
network, open a browser and go to:
http://www.Bose.com/soundtouch_app
Tip: If you want SoundTouch to play your
iTunes
®
or Windows Media
®
Player music
library, use the computer where your music
library is stored.
2. Download and install the SoundTouch app
on your computer. You are now ready to
connect the system to your network.
Note: Do not connect any cables to the
system until the app instructs you to connect
the cables.
