Bose SoundTouch Service Manual

3
PRODUCT DESCRIPTION
The Bose
®
SoundTouch
TM
Wireless Pedestal
is sold as part of the Wave
®
SoundTouch
music system, which consists of a Wave
®
Music system III, Wireless Pedestal and
remote control.
The wireless pedestal sits under the Wave
®
Music system and connects to the WMS III
back panel via a Bose Link pigtail type cable.
It derives power from the WMS III system and
contains the Wi-Fi adapter module that
allows connection to the customer’s wireless network.
The SoundTouch wireless pedestal is compatible with the Wave
®
music system III only.
Below description is from the owner’s guide for the Wave
®
SoundTouch music system.
Your Wave
®
SoundTouch music system provides an elegant way to bring high quality sound
wirelessly into any room. With the addition of the SoundTouch pedestal to the Wave
®
music
system, you can listen to Wi-Fi music at the touch of a button. Use the free SoundTouch app to
set up and control your system.
System features
• Lifelike, room-filling sound from a compact system that can play all of your music.
• Enjoy all your music sources at the touch of a button: Internet radio, your music library, DAB/
FM/AM radio, and CDs.
• Stream your music via AirPlay from your iPhone, iPad, iPod devices
• AUX connector enables playback from an external media player
• An Ethernet connector enables wired access to your home network.
• USB connectors for network setup.*
• Free SoundTouch™ app for system setup and control
* The USB connectors on the back of the system (SETUP A and SETUP B)
are for setup only. The connectors are not designed to charge smartphones,
tablets, or similar devices.
With SoundTouch, you can stream Internet radio, music services, and your music library.
If you have Wi-Fi at home, you’re ready to enjoy your favorite music in any room you want.
Key benefits
• Enjoy wireless access to Internet radio, music services and your music library.
• Stream your favorite music easily with personalized presets.
• Works with your existing home Wi-Fi network.
• Free SoundTouch app for your computer, smartphone, or tablet provides more powerful control.
• Simply add additional systems at any time for a multi-room listening experience.
• Wide selection of Bose audio systems lets your choose the right solution for any room.

Bose SoundTouch Specifications

General

Number of drivers	-
Number of speakers	1
Audio output channels	2.0 channels
Recommended usage	Universal
Remotely operated	Yes
Card reader integrated	No
Product type	Stereo portable speaker
Product color	Black
Product design	Other
Volume control	Digital
Impedance	- Ω
Frequency range	- Hz
RMS rated power	- W
Display	OLED
Depth (imperial)	2.5 \
Width (imperial)	9.8 \
Height (imperial)	5.8 \
Cables included	AC
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wireless
Power source type	Battery

Weight and Dimensions

Depth	64 mm
Width	249 mm
Height	147 mm
Weight	1448 g
