Bose SoundTouch Service Manual

6
MAIN PART LIST
SoundTouch
TM
Wireless Pedestal (refer to Figure 2)
Important Note: When replacing the programmed Wi-Fi module PCB (item 7 above), the serial
number and country code MUST be set on the replacement board before returning the unit to the
customer. Refer to pages 35 and 36 for procedures.
Item
Number
Description Part Numbe
r
Qty Note
1 ENCLOSURE, TOP, W/PSA (12) & BEZEL (13) 1 3
GRAPHITE 625542-001S
WHITE 625543-001S
SILVER 625544-001S
2 ENCLOSURE, BASE, BLK, W/CABLE (4) 625545-001S 1 3
3 SCREW, TAPP, 4-16X.38, PAN, XREC 288372-006 5
4 CABLE, 9 POS, BOSE
®
LINK, 3IN, BLK 369837-0010 1 2, 3
6 CABLE, FFC, 0.5mm, 40 POS, 120mm 355832-0120 1 3
7 WI-FI MODULE, PROGRAMMED, SVC 625125-031S or
625125-041S
1 3, 4
8 PCB ASSY, SOUNDTOUCH, I/O, SVC 355647-001S 1 3
9 FOOT, PRESS ON 285786-001 4 3
10 SCRIM, CONN, LRG 361216-0010 1
11 FOAM, LED, BLOCKING 371043-0010 1
12 BEZEL, PSA 371045-0010 1 2
13 BEZEL ASSY, MED SLV, PAINTED 370447-007 1 2, 3
14 LABEL, I/O 374010-0010 1
15 SCREW, 6-13x.44, PAN, XREC/SQ. 288374-007 6
16 LABEL, PRODUCT, 1.4X2.8IN - 1 2, 3
17 CABLE ASSY, FFC, 31 POS, 120mm 370236-0120 1 3
18 SCRIM, RESET BUTTON 374284-0010 1


Bose SoundTouch Specifications

General

Number of drivers	-
Number of speakers	1
Audio output channels	2.0 channels
Recommended usage	Universal
Remotely operated	Yes
Card reader integrated	No
Product type	Stereo portable speaker
Product color	Black
Product design	Other
Volume control	Digital
Impedance	- Ω
Frequency range	- Hz
RMS rated power	- W
Display	OLED
Depth (imperial)	2.5 \
Width (imperial)	9.8 \
Height (imperial)	5.8 \
Cables included	AC
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wireless
Power source type	Battery

Weight and Dimensions

Depth	64 mm
Width	249 mm
Height	147 mm
Weight	1448 g
