12
MAKING THE CONNECTIONS
* Inserting a plug into the Input Jack will automati-
cally switch the unit on.
* Before connecting or disconnecting any patch cords,
be sure all the volume controls in your system are set
to minimum. This will help prevent any damage to
system components.
* To prevent malfunction and/or damage to speakers
or other devices, always turn down the volume, and
turn off the power on all devices before making any
connections.
Connecting the AC-2 to a single amplifier
AC Adaptor
(
PSA-Series; Optional
)
Electric Guitar
Amplifier
OUT DC 9V / 200 mA
* Always make sure to have the volume level turned
down before switching on power. Even with the
volume all the way down, you may still hear some
sound when the power is switched on, but this is
normal, and does not indicate a malfunction.
* When operating on battery power only, the unit's
indicator will become dim when battery power gets
too low. Replace the battery as soon as possible.
To Next Page
