Boss DD-8 - Direct Mute Setup; Stereo Delay Setup Options

Setting the Output Method
16
Direct Mute
This produces eect output with B input and A output.
A
B
Guitar Amplier Guitar
DD-8
RETURN SEND
INPUT
* The direct sound is not output from A, regardless of whether
the eect is on or o.
* Be sure to lower the output level of any device being
connected.
Stereo
With A input and A/B output, this provides mono-in stereo-out
delay.
A
B
A
Guitar Amplier Guitar DD-8
With A/B input and A/B output, this provides stereo-in stereo-out
delay.
A
B
B
A
Guitar Amplier Guitar Stereo Eect Unit
(chorus, anger etc.)
Keyboard
DD-8
* You can select any of three types of stereo delay modes.
For more information, refer to “Setting the Mode for Stereo
Delay” (p. 18).
