9
Operating the Unit
fig.05
1.
When you have made the necessary
connections, set the knobs as shown in
the illustration.
2.
Depress the pedal switch to turn the
effect on. (Make sure the CHECK indi-
cator lights.)
3.
Adjust the depth of the Distortion
effect using the DIST knob and GAIN
BOOST knob.
* Turning both knobs all the way up will result
in increased noise.
4.
Adjust the tone using the TONE knob.
5.
Adjust the degree of low-end boost
with the BOTTOM knob.
6.
Adjust the LEVEL knob so that the
level of the sound obtained when the
effect is on is equal to that obtained
when it is off.
4536
