Bostitch IC60-1-E - Page 2

IC60-1-E
Xmm
A 270 mm
B 280 mm
C 133 mm
D 2.58 kg
E 91.85 dB / 4 dB
F 96.08 dB / 4 dB
G 83.10 dB / 4 dB
H
2.53 / 1.26 m/s
2
BAR/
LTR
I 7.0 Bar
J 4.9 Bar
K 4.48 Ltr
L(a) 1
L(b) 1
M BC602
N BC603
O O-lube
Q(b)
R
Q(a)
P N
Q(a) 2.0-2.3 mm
Q(b) 25-60 mm
R 4.3-5.6 mm
S 300-350
T U
T 129.6-130.2 mm
U 4.0 mm
T
U
FIG 1
FIG 2a
FIG 2b-2c
FIG 3
IC60-1-E
