BougeRV E30 - Product Structure Overview; Handle Installation Guide

5
4.3 Product Structure
Compressor cooling hole
Fuse
Power interface
Three-level switch for battery protection
Elastic handle
Digital touch screen & Control panel
Seal rubber ring
Refrigerator cabinet
4.4 Handle Installation
Step 1: Disassemble
the screw (M6.16) with
the hex key and keep
the screw. 8 pcs
screws in total.
Step 2: Put a fixed handle
seat part on the two holes
and install the handle
parts with a screw by
using the hex key.
Step 4: Put another
handle seat parts on
the handle tube and
also pay attentionto the
direction of the handle
tube.
Step 5: Align the
mounting screw holes
and tighten them with
the hex key and screws.
Pls also install the other
handle on the other
sides in the same way.
Step 3: Put the handle
tube into the installed
hand seat, pay attention
to the direction of the
groove, and align the
inner diameter of the
handle hole.
