4 Assembly
MN031-447-S0-20101217-EN NightKNIFE / Ligator 19
4. Slide the insertion aid E with the blade along the fixed
jaw A1 in the arrow direction until it reaches the stop.
321
5. Ensure that the blade with insertion aid E is positioned in
the middle at the marked position.
6. If necessary, use your fingers to position the insertion
aid E1 in the middle.
