4 Assembly
18 NightKNIFE / Ligator MN031-447-S0-20101217-EN
4. Assembly
WARNING
Risk of patient injury from non-sterile ligation
instruments!
The ligation instrument is not sterile as delivered. Clean
and sterilize the instrument before using it.
Pos: 6 /679-BOWA/HF-I nstrumente/Ligator "NightKNIFE"/4.1 Mon tage der Klinge @ 5\mod_127798 5392590_6.doc @ 40655 @ 2
4.1. Attaching the replaceable blade with the
insertion aid (only for NightKNIFE with
replaceable blade)
;
The blade and insertion aid have been cleaned and
disinfected ( see section 7.5, page 42).
1. Remove the blade and insertion aid E from the sterile
package.
2. Rotate the jaw insert A with the fixed jaw A1 facing
upward to open the jaws.
3. Insert the fixed jaw A1 between the blade E2 and the
insertion aid E1 and press the insertion aid E1
downward in the arrow direction to release the blade.
