7 Preparation
MN031-447-S0-20101217-EN NightKNIFE / Ligator 37
1
2
3
4
5
6
NOTE
Risk of material damage to the jaw insert from metal
brushes!
X
Use only plastic brushes to clean the jaw insert.
2. Using a plastic brush and a steam sprayer, remove
contamination from the areas shaded in grey.
x Jaws 1: exterior surfaces top and bottom;
electrode surfaces
x Mechanism 2: openings top and bottom
x With NightKNIFE: ratchet mechanism 3
x With NightKNIFE: spring 5
3. With NightKNIFE: using a sharp object, clean the inner
edges of both grooves 6.
MN031-447-S1 EN
