BÖWE M30 - Page 75

65
M21-M26-M30
from tank 1 to still
still maintenance
P45
P59 P73
from tank 1 to cage
P56
P70
filling tanks
pumping out still residues
preparation / stock solution
rinsing water separator
draining sluice-tank
maintenance filter 2
maintenance filter 1
Multi-maintenance 1
maintenance adsorption unit
Multi-maintenance 2
P51
P55
P53
P54
P52
P47
P48
P49
P50
P46
P67
P69
P68
P65
P66
P62
P63
P64
P61
P60
empty tank 3
P84
empty tank 2
empty tank 1
from tank 2 to tank 3
from tank 2 to tank 1
from cage to tank 3
from cage to tank 2
from cage to tank 1
from cage to still
from tank 3 to still
from tank 2 to still
P81
P83
P82
P79
P80
P76
P77
P78
P74
P75
maintenance and utility programs
deodorizing
short drying
P43
P44
P57
P58
from tank 3 to cage
from tank 2 to cage
P71
P72
801727
11. Maintenance 11.
P59
From tank 1 to distillation
Strip tank 1
P60
From tank 2 to distillation
Strip tank 2
P61
From tank 3 to distillation
Strip tank 3
P62
From cage to distillation
Pump to distillation
P63
From cage to tank 1
Pumping to tank 1
P64
From cage to tank 2
Pumping to tank 2
P65
From cage to tank 3
Pumping to tank 3
P66
From tank 2 to tank 1
Refill clean tank
P67
From tank 2 to tank 3
Refill clean tank
P68
Empty tank 1
For pumping out the work tank. Empty the machine
P69
Empty tank 2
For pumping out the clean tank. Empty the machine
P70
Empty tank 3
For pumping out tank 3. Empty the machine
Program overview sign
