BÖWE P 300 - Machine Dimensions and Floor Load

17
6. Installation
6.2.2 Machine dimensions
Slimline Crossline
P 240 /P 300 P 240 /P 300
P 300 USA /P 350 USA P 300 USA /P 350 USA
_______________________________________________________________________________
Width mm 1080 inch 42.5 mm 1840 inch 72.4
Depth mm 2140 inch 84.2 mm 1365 inch 53.7
Height without cool-down flap mm 2105 inch 82.9 mm 2105 inch 82.9
Height with cool-down flap mm 2300 inch 90.6 mm 2300 inch 90.6
6.3 Floor load
The place of installation must conform to the floor load which is composed of:
- static load = machine weight + max. solvent filling and
- dynamic load = centrifugal cage force with normally
distributed, extraction-damp garments.
The force created during extraction must also be taken into account
(floor, supporting walls etc.). Resonances are not permissible.
Please consult building specialists.
6.3.1 Dimensions
Slimline Crossline
P 240 /P 300 P 240 /P 300
P 300 USA /P 350 USA P 300 USA /P 350 USA
________________________________________________________________________
Depth* mm (inch) 1200 (47.2) 1310 (51.6) 1200 (47.2) 1310 (51.6)
Width* mm (inch) 1080 (42.5) 1080 (42.5) 1080 (42.5) 1080 (42.5)
Portion of the floor surface
for the force transmission m² (sq.ft.) 1.3 (14) 1.41 (15.2) 1.3 (14) 1.41 (15.2)
Weight without solvent kg (lb) 980 (38.6) 1080 (42.5) 1080 (42.5) 1100 (43.3)
Weight with solvent
(stat. load) kg (lb) 1300 (51.2) 1470 (57.9) 1400 (55.1) 1490 (58.7)
Centrifugal cage force
(dyn. load) N 4800 6000 4800 6000
Floor load (stat. + dyn. load)
- Standard drive N/m² 13600 14500 14300 14600
*Portion of the complete machine dimension, that is decisive
for the floor load and the centrifugal cage force.
Regarding the foundation work please consult building experts.
They will take machine-related as well as local particulars into account
and find the best solution.
Please use a load dispatcher frame if the permissible floor load is inadequate.
