BÖWE P 300 - Table of Contents

2
Table of contents
Page
1. General information 4
2. Machine side profile 5
3. Transportation 6
3.1 Entry 7
4. Foundation
4.1 Foundation measurements
Slimline 8
Crossline 9
4.2 Anchoring 10
4.3 Noise or vibration insulation 10
5. Machine fixing
5.1 Machine trough 11
5.2 Anchoring methods 11
5.3 Cemented-in stone bolts 12
5.4 Safety expanding anchors 12
5.5 Threaded rods (bored-through ceiling) 12
5.6 Adhesive plugs /shear connector 13
6. Installation
6.1 Surrounding conditions 14
6.1.1 Regulations 14
6.1.2 Temperature 14
6.1.3 Structural surroundings 14
6.2 Place of installation 15
6.2.1 Required space
Slimline 15
Crossline 16
6.2.2 Machine dimensions 17
6.3 Floor load 17
6.3.1 Dimensions 17
