32
9. Technical data
P 240 with /without Slimsorba
Heating steam electr.
CONSUMPTION DATA:
CONSUMPTION PER LOAD*
El. energy total without /with Slimsorba kWh 2.2 /2.4 7.5 /9.3
El. energy drying without /with Slimsorba kWh 2.0 /2.1 3.2 /3.3
El. energy still kWh - 4.3
Saturated steam drying without /with Slimsorba kg 2.0 /2.7 -
Saturated steam still kg 5.0 -
Cooling water drying without /with Slimsorba l 45 /60 50 /60
Cooling water still l 65 75
Compressed air (6 bar ) l 6 6
OTHER DATA:
Still throughput (DIN 11916) max. l/h 120 75
Filter throughput l/h 4000 4000
Filter surface ECO-filter m
2
2.4 2.4
Weight without solvent Slimline /Crossline kg 980 /1080 980 /1080
Weight with solvent Slimline /Crossline kg 1300 /1400 1300 /1400
Carbon-filling Slimsorba kg 10 10
Floor surface Slimline /Crossline m
2
2.3 /2.5 2.3 /2.5
Used floor surface*** Slimline /Crossline m
2
1.3 /1.3 1.3 /1.3
Centrifugal cage force N 4800 4800
Floor load (stat. and dyn.) max.
. Slimline /Crossline N/m
2
13600 /14300 13600 /14300
Noise level dB(A) 64 64
HEAT BALANCE:
Heat eliminated by cooling water****:
with /without Slimsorba kJ/h 26000 /25000 27000 /26000
Heat radiation to the ambient*:
with /without Slimsorba kJ/h 9500 /9300 9500 /9300
* Values apply to a standard 2-bath-cycle, 1. bath to distillation at cooling water inlet temperature + 12 °C (53.6 °F).
Drum outlet temperature 50 °C (122 °F), condensation pressure 22 bar (319 psi), drying 18 minutes, reduction 6 minutes,
steam supply 4 - 5 bar (58 - 72.5 psi) saturated steam, ambient temperature + 1 to + 40 °C (+ 34 to 104 °F),
with Slimsorba 3 min. reduction, 6 min. adsorption.
*** used part of floor surface for force transmission see point 6.3.1
**** refers to water without any additive
Subject to technical changes!
