BÖWE P18 - Settings and Optimum Operating Values

21
P12 /P15 /P18
5. Settings and Optimum Operating Values
Machine P12 P15
Basic value:
Steam pressure (saturated steam) bar(psi) 4–5(58–72.5) 4–5(58 – 72.5)
Steam temperature (max. permitted) °C(°F) 150(302) 150(302)
Cooling water pressure bar(psi) 2-4(29-58) 2-4(29-58)
Cooling water temperature, max. °C(°F) 25(77) 25(77)
Compressed air bar(psi) 6(87) 6(87)
Cage speeds:
Cleaning/ RPM 35 35
Spinning RPM 500 500
Reversing cycle (cleaning) sec. 10/1/10 10/1/10
Low level l(US gal) 30(7.9) 35(9.2)
High level l(US gal) 60(15.8) 70(18.5)
Pump pressure (max.) bar(psi) 2.5(36.2) 2.5(36.2)
Filter surface, economy filter m
2
(ft
2
) 2.7(29.0) 2.7(29.0)
Filter powder (only for machines without emission-
free still rake out system) kg(lb) 1.2(2.6) 1.2(2.6)
Tank I: optimum filling volume (high level) l(US gal) 60(15.8) 75(19.8)
Tank III: optimum filling volume l(US gal) 60(15.8) 75(19.8)
Detergent solution cooler:
Detergent solution thermal sensor:
Detergent solution cooler ON °C(°F) 15–30(59-86) 15 – 30(59-86)
Refrigeration technology:
Filling capacity, cooling agent R 404A kg(lb) 4.6(10.1) 4.6(10.1)
Nozzle size: solvent cooling no. 03 03
Drying + Reduction no. 06 06
High pressure control switch ON approx. bar(psi) 21(319) 21(319)
High pressure control switch OFF approx. bar(psi) 26(377) 26(377)
Low pressure control approx. bar(psi) 1(14.5) 1(14.5)
Drying:
Cooling water regulator setting:
Adjust 4 – 6 min. after start of drying bar(psi) 20(290) 20(290)
Temp. sensor, cage entry (gentle drying) °C(°F) 60(140) 60(140)
Temp. sensor, cage exit °C(°F) 50(122) 50(122)
Temp. sensor after cooler:
Control value, drying °C(°F) 40(104) 40(104)
Control value, cycle end °C(°F) 15(59) 15(59)
Safety thermostat, heater battery (elec. only) °C(°F) 110(230) 110(230)
