5
ENGLISH
705 S3 / 706 S3 / 707 S3
The 705 S3, 706 S3 and 707 S3 are primarily designed to be
mounted on a dedicated oor stand (FS-700 S3), but may be
placed on a shelf if preferred. However, it should be noted that
this offers less exibility to optimise the speaker’s performance.
If shelf placement must be used, we recommend using the foam
plugs (supplied) to optimise port performance (see Section 4:
Fine-Tuning).
In both installation cases, the speakers’ tweeters should be
approximately at ear height at your usual listening position.
Note: If using a shelf, ensure that it is strong enough to
properly support the weight and fit the four self-adhesive
rubber feet to the underside of the speaker.
Important Safety Notice
Sharp spikes, do not touch.
The spike feet are designed to pierce carpet and rest on the
oor surface. Initially, screw the lock nuts onto the spikes just
far enough to leave the nuts oating just above the carpet when
the spikes are resting on the oor beneath. Then, screw the
spikes fully into the threaded inserts in the plinth. If the cabinet
rocks when placed on the oor, unscrew the two spikes that do
not touch the oor until the cabinet rests rmly without rocking.
Finally, lock the nuts against the base by using the supplied
spanner to gently tighten the nut whilst using the supplied tommy
bar to stop the spike foot rotating. It may be more convenient to
t and adjust the spike feet after speaker positioning has been
optimised.
If there is no carpet and you wish to avoid scratching the oor
surface, use either a protective metal disc (a coin perhaps)
between the spike and the oor, or use the supplied rubber feet.
Fit the rubber feet and level the cabinet in the same manner as
with the spike feet.
<15mm
<29mm
<30mm
<31mm
702 S3 703 S3 / 704 S3
