Bowflex 3.1 Bench - Step 2: Attaching Pads

6
STEP 2: Attaching Back Pad and Seat Bottom to Bench Frame
Parts
• Bench Frame Assembly from Step 1
• Back Pad (#4)
• Seat Bottom (#5)
Hardware Qty
• 5/16 x 2 1/2 inch Bolts (#10) 10
• 5/16 Washers (#14) 10
Tools
• 3/16 Allen Wrench
2-1 Align the Seat Pad to the Bench Frame Assembly and secure with the hardware shown.
2-2 Tighten hardware.
2-3 Align the Seat Pad to the Bench Frame Assembly and secure with the hardware shown.
2-4 Tighten hardware.
4
5
10
14
