11. Attach the new Motor Mount to the Motor. Be sure the Belt Tensioner
Screw is properly oriented toward the rear of the machine when the Motor is
re-installed.
12.LightlyattachtheMotorAssemblytotheFrame.Besuretoonlynger
tighten the hardware.
13. Loop the Drive Belt onto the Motor Pulley. With the Drive Belt looped onto
the Motor, carefully roll the Drive Belt onto the Drive Pulley in a clockwise mo-
tion. Be sure the Belt does not come off of the Motor Pulley.
Keep ngers out of any pinch opportunities when turning the
Pulleys.
14. Roll the Drive Pulley clockwise until the Drive Belt is fully installed. Con-
tinuetorolltheBeltforwardwhileaddingsidepressurewithngerstoalignas
necessary.
15. With the Motor Assembly loosely attached to the Frame, turn the Belt
Tensioner Screw to the previous level. This will tighten the Drive Belt to the
previous tension level.
16.Usinga6mmhexwrench,fullytightenthescrewsthatattachtheMotor
Assembly to the Frame.
17. Re-install all remaining parts that were removed in reverse order.
18.AttachthepowercordandturnontheTreadmillbyippingthepower
switch to ON.
19. From the Power Up (or Welcome) screen, push and hold down the
PAUSE/STOP button and Down arrow button for about 5 seconds to go into
the Machine Setting Mode. The Console display will show the TOTAL HOURS
screen.
Motor
Drive Belt
Belt Tensioner Screw
Motor Mount
