9. Using a #2 Phillips screwdriver, remove the 2 indicated screws from
the Motor Control Board Cover. Lift and remove the Motor Control Board
Cover.
10. Remove the Speed Sensor Connector from the Motor Control Board.
Speed Sensor Connector
Motor Control Board
(MCB)
Motor Control Board Cover
