Bowflex BXT116 - Page 159

159
11. Attach the new Speed Sensor Connector to the Motor Control Board.
12. Route the new Speed Sensor Cable along the Frame.
13.UsingreplacementZip-Ties,securetheSpeedSensorCabletotheFrameandtrimtheexcessfromtheZip-Ties.BesurenottocuttheSpeed
Sensor Cable.
14. Using a #2 Phillips screwdriver, attach the new Speed Sensor
15. Re-install all remaining parts that were removed in reverse order.
16. Final Inspection
Inspect your machine to ensure that all hardware is tight and components are properly assembled.
Do not use until the machine has been fully assembled and inspected for correct performance in accordance with the Owner’s
Manual.
