107
2. Gently unsnap and remove the Handlebar Shrouds from the Console
Assembly.
3. Using a #2 Phillips screwdriver, remove the 12 indicated screws from
Console Backing. Be sure not to mix the self-tapping screws from the
previous step.
4. Using a #2 Phillips screwdriver, remove the six screws from the Right
and Left Trays and remove them from the Console and Handlebar As-
sembly.
1. Unplug the power cord from the machine and wait 5 minutes. Place the power cord in a secure location.
!
To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the
power cord from the wall outlet and wait 5 minutes before cleaning, maintaining or repairing this
machine. Place the power cord in a secure location.
Handlebar Shroud
Right Tray
Left Tray
To Next Page
