20. To attach the Lower Right Rope Stopper, pull the end of the new
Lower Right Rope through the frame and attach the Stopper. Set the
Stopper into the frame.
21. Using the routing wire, slowly pull the Lower Right Rope through
the Right Platform Frame and attach the Securing Ball.
22. With the Securing Ball attached, safely release the Lower Rope.
23. Re-assemble the machine in the reverse order of when the parts
were removed.
24. Final Inspection
Inspect your machine to ensure that all hardware is tight and compo-
nents are properly assembled.
Do not use until the machine has been fully assembled
and inspected for correct performance in accordance
with the Owner’s Manual.
