Bowflex HVT - Page 115

115
13. Remove the Front Middle Pulley Shroud from the Middle Pulley
Arm and place outside the work area.
14. Using a 6mm hex wrench, remove the 4 screws that attach the
Middle Pulley Arm to the Frame Assembly. Be sure to be prepared to
support the weight of the Arm before removing the hardware.
X4
6mm
Middle Pulley Arm
