Bowflex HVT - Page 30

30
15. Slide the provided Brake Arm Spacer onto the Servo Motor Arm.
16. With the Brake Arm Spacer installed, replace the Brake Assembly and
secure the Servo Motor following the guidelines provided from Steps 9 and
10.
17. Skip to Step 21.
Servo Motor Arm
Brake Arm Spacer
Brake Arm Spacer Brake
Assembly
Servo
Motor
