7. With all the Platform Decking fully pushed toward the Fan Assembly,
use a Standard Screwdriver to pry up the Platform Decking that is the
furthest from the Fan Assembly.
Note: Be sure to place the Platform Decking off to the side in the order it
is removed. This will help with re-assembly.
8. Remove the next piece of Platform Decking and place it in the order
removed. This will help with re-assembly.
9. Using a 6mm hex wrench, remove the four indicated screws from the
Front Platform Frame.
10. Slightly pivot the Platform Frame Assembly upward and safely remove
the Front Platform Frame.
11. Flip the Front Platform Frame over. Using a #2 Phillips screwdriver,
remove the Platform Corner Shrouds from it.
Right Platform Frame
Front Platform Frame
C
X2
9
10
9
#2
Platform Corner Shroud
